HLD Series Hopper Mixer(Bin mixer)

Keywords:
Category: Mixer
Principle Through years of studying, comparing and absorbing both domestic and foreign machines, we develop our own design of HLD series hopper mixer(Hopper mixer,hopper mixing equipment).This machine consists of …
Order
Detail Picture

HLD Series Hopper Mixer(Bin mixer)

Principle

Through years of studying, comparing and absorbing both domestic and foreign machines, we develop our own design of HLD series hopper mixing machine (Hopper mixer,hopper mixing equipment,Bin Mixer).
This machine consists of stand, rotary frame, driving, braking, control system components. The driving system to automatically mixed according to the set time, speed and other data. Mixed operation ended, rotary frame vertical stop, hopper fall to the ground automatically, the machine stops, and print process data. Loosen the lock device of rotary rack, promotes the hopper to the next process. Loosen the lock device of rotary rack, promotes the hopper to the next process.



Features
1. This machine is our widely absorbing, digesting foreign advanced technology, combined with the new type conditions of successful research and development. Reasonable structure, stable performance, convenient operation, the machine without dead angle, no exposed screws. The rotary body (mixing hopper) into a 30 degree angle with the axis of rotation, mixed material in the hopper with rotary turning, along the bucket wall tangential movement, have a strong turnover and high-speed tangential movement, so as to achieve the best effect of mixing. Using PLC automatic control, and set the infrared safety device and anti misoperation device discharge valve, ensure safety in production. Through the process of material can be different in the same container, do not require frequent feeder, feeding program. Control of dust and cross pollution effectively, reduce the loss of material, hierarchical control material, optimize the production process, in full compliance with the GMP requirement of pharmaceutical production.
2.The structure is reasonable; adopt double hoisting devices, motor rotation, flexible coupler. The performance is stable, the upkeep and maintenance and simpler, and there's no problem of leakage.
 3. Adopt programmed control system, technical parameters setting system, machine stops system for safety, automatic accurate positioning system, operation, and automatic record printing system, that fully meet processing equipment of pharmaceutical companies. Fully automatic production is realized, and the operation is very simple.
 4. To ensure the quality of the machine, we adopt high quality out purchased parts for this machine.
 5. Equipped with fine manufactured hopper that fully meet the requirements of GMP, no residues of discharge, and it's easy for cleaning or washing
6. We supply series product for material conveying. It forms advanced process together with the hopper mixing machine.
6.for the feeding system for this mixer , it can choose vacuum feeding or negative feeding or others .
Remarks: If customer has any special requirements, please special order.




Application
It's widely used as the mixing machine for solid medicine powder in pharmaceutical industry worldwide. The mixing uniformity is high, the material vessel is movable, these are very convenient for material loading, mixing, discharging and cleaning. It's easy to integrate with the upstream and downstream process, the problem of cross pollution and fly-dust caused by multi-material-transferring are solved. Various of material vessel might be equipped with this machine, so to meet the mixing requirement of large batch capacity, and multi-varities.



Technical datas

spec parameter

HLD-800

HLD1000

HLD1200

HLD-1500

HLD2000

HLD3000~6000

A

2900

3100

3175

3350

3770



B

2550

2600

2700

2850

3300



C

1850

1900

1950

2100

2650



D

1600

1650

1700

1800

2050



E

700

700

700

700

700



F

1000

1200

1200

1200

1200



G

1500

1500

1500

1600

1600



L

3050

3300

3400

3550

3550



K

2000

2150

2150

2200

2200



power kw

7

7

7

9.7

9.7



net load

400

500

600

750

1000



weight

2500

2800

3000

3500

4000
